UV Roll To Roll Printer RJ 1802R

Name: UV Roll To Roll Printer RJ 1802R
Brand: MEHTA CAD CAM SYSTEMS PVT. LTD.
Price: 1150000.00 INR
Availability: InStock

Price 1150000.00 INR/ Unit

Get a Price/Quote

MOQ : 1 , , Unit

UV Roll To Roll Printer RJ 1802R Specification

Print Technology
UV Inkjet

Features
UV LED Curing, High Durability Prints, Low Odor, Scratch-resistant, Fast Drying

Cabinet Material
Powder Coated Steel

Function
Print Only

Interface
USB 2.0 / Ethernet

Processor Type
Industrial Control Processor

Power Supply
AC 220V 10%, 50/60 Hz

Capacity
Continuous Roll-to-Roll feeding

Print Speed
12-18 sqm/h

Humidity %
20-80%

Weight
480 kg

Working Temperature
20-28C

Processor Speed
1.5 GHz

Usage & Applications
Banner, Flex, Vinyl, Wallpaper, Window Film, Advertising Media Printing

Noise Level
< 60 dB

Condition
New

Material
Metal Body with Aluminum Platform

Dimensions
3190 mm (L) x 880 mm (W) x 1390 mm (H)

Gross Power
3.5 kW

Voltage
220V / 50Hz

Automatic Grade
Automatic

Color Print Speed
12-18 sqm/h

Black Print Speed
Same as Color

Maximum Paper Size
1800 mm (Roll-to-Roll)

Maximum Resolution
1440 dpi

Use
Industrial / Commercial Printing

UV Roll To Roll Printer RJ 1802R Trade Information

Minimum Order Quantity
1 , , Unit

Supply Ability
10 Units Per Month

Delivery Time
1 Months

About UV Roll To Roll Printer RJ 1802R

Technical Specification:

Country of Origin	Made in India
Model/Type	RJ 1802R
Brand/Make	Mehta
Max Printing Width	1800 mm
Operating System	Windows
Print Size	1800 mm

High efficient uv-led technology.

Four layers printing, exquisite and vivid color output.
International environmental standard UV inks.
Odorless, LESS environmental impact.
Optional eight-color print mode (CMYKLCLMLK+W) Superior image quality on a wide array of medias with uv ink.

Exceptional Print Quality and Speed

The RJ 1802R delivers outstanding print quality with a maximum resolution of 1440 dpi, powered by dual Epson i3200-U1 printheads. Operating at speeds of 12-18 sqm/h, it maintains consistent color and sharpness, even at high throughput, ensuring professional results across various advertising media and designs.

Versatile Media Compatibility

This printer supports a diverse range of media-such as PVC, PET, vinyl, wallpaper, mesh, banners, and film-with thickness up to 2 mm. Its automatic roll-to-roll feeding system makes continuous production seamless for applications ranging from window films to large flex banners.

Durable, Fast-Drying UV Prints

Equipped with an advanced UV LED lamp drying system and water circulation + air cooling, the RJ 1802R ensures prints are instantly cured, scratch-resistant, and low-odor. This means your products can be handled immediately and will offer long-lasting durability even in demanding environments.

FAQ's of UV Roll To Roll Printer RJ 1802R:

Q: How does the dual Epson i3200-U1 printhead configuration improve printing results?

A: The dual Epson i3200-U1 printhead setup enables faster print speeds while maintaining high-resolution (up to 1440 dpi) and consistent color output. This configuration is ideal for large-volume commercial applications where detail and efficiency are both essential.

Q: What types of media can the RJ 1802R print on, and what is the maximum thickness supported?

A: The RJ 1802R accommodates PVC, PET, vinyl, film, wallpaper, banner, and mesh media, supporting thicknesses up to 2 mm. This versatility makes it suitable for advertising products, window graphics, and flex printing.

Q: When is UV LED curing ink advantageous in commercial printing?

A: UV LED curing ink is beneficial for producing prints that are instantly dry, scratch-resistant, and emit low odor. It supports high-speed operations and provides long-lasting results suitable for indoor and outdoor media, ensuring prompt turnaround times for businesses.

Q: Where is this printer most commonly used, and by whom?

A: The RJ 1802R is widely used in advertising agencies, print shops, manufacturers, exporters, and suppliers across India, particularly for creating banners, vinyl signs, wallpapers, and window films in both industrial and commercial environments.

Q: What is the process for switching supported media types on the RJ 1802R?

A: Media switching is streamlined by the automatic roll-to-roll feeding system. Simply load the chosen media onto the roll platform and configure the relevant settings on the touch screen LCD control panel; the printer automatically adjusts for optimal feeding and curing.

Q: How does the water circulation and air cooling system enhance print durability?

A: The water circulation plus air cooling ensures that the UV LED lamp maintains optimal temperature during printing, preventing overheating and promoting consistent ink curing. This process produces prints that resist scratches and fading over time.

Q: What are the main benefits of using the RJ 1802R for banner and flex printing?

A: Key advantages include high-speed, high-resolution prints, instant drying, robust durability, and support for a wide variety of media sizes. These features lead to efficient production workflows with consistently professional outcomes.
